Heat-Recovery Energy-Saving Commercial Hood-Type Pass-Through Dishwasher (HDW80CH / HDW80L): B2B Engineering Overview
The Heat-Recovery Energy-Saving Commercial Hood-Type Pass-Through Dishwasher (HDW80CH / HDW80L) is an industrial-grade dishwashing solution engineered for high-throughput hotels, central kitchens, and institutional catering across the Middle East (GCC) and Southeast Asia. Pairs with entry and exit stainless steel sorting tables with pre-rinse sinks for a continuous linear or corner dishwashing line. Fabricated with AISI 304 (1.2mm–1.5mm) deep-drawn wash tank, sus316l booster heating elements & stainless steel anti-clog wash/rinse arms, it delivers verified operational output (HDW80CH: 710×815×1995mm (15.1kW, 60 Racks/h) | HDW80L: 810×915×1605mm (15.75kW, Fits Sheet Pans & Trays)) under 380V–415V / 3Ph+N+PE / 50–60Hz supply and complies with IEC 60335-2-58, NSF/ANSI 3 (Commercial Warewashing 82°C Thermal Sanitization), DIN 10510 / 10512, CE, SASO.
Top Latent-Steam Heat-Recovery Condenser & 82°C NSF Sanitizing Booster
- Integrated Steam-to-Water Heat-Recovery Heat Exchanger (HDW80CH: 710×815×1995mm (15.1kW, 60 Racks/h) | HDW80L: 810×915×1605mm (15.75kW, Fits Sheet Pans & Trays)): Captures hot waste vapor when the hood is closed to pre-heat incoming 15°C cold tap water up to 45°C–50°C for free, cutting rinse booster power draw by 30% and eliminating overhead exhaust hood ductwork.
- NSF/ANSI 3 Compliant 82°C–85°C Atmospheric Rinse Booster & 60 Racks/h Output: Guarantees thermal sanitization on every 500×500mm dish rack (or 600×400mm sheet trays on wide HDW80L).
- Deep-Drawn AISI 304 Wash Tank & Anti-Clog Concave Spray Arms: Dual upper and lower revolving stainless steel wash and rinse arms strip dried grease in 60/90/120-second cycles.
- Built-In Peristaltic Detergent/Rinse-Aid Pumps & Double Scrap Filters: Prevents food debris from entering the high-head wash pump. Factory baseline configuration for HDW80CH / HDW80L: Hood-Type Pass-Through Dishwasher.
Water, Chemical & 52.5 kWh/Day Stewarding TCO Analysis
In commercial stewarding operations, energy, water, and chemical dosing represent over 75% of lifecycle cost. Operating across a 6-hour peak washing schedule (58% effective heater duty factor), the HDW80CH / HDW80L consumes approximately 52.5 kWh/day while holding fresh rinse water consumption to just 2.0–2.4 Liters per rack. Tool-free removable stainless scrap screens and spray arms allow complete daily tank flushing in under 6 minutes. Configured specifically as a Heat-Recovery Energy-Saving Commercial Hood-Type Pass-Through Dishwasher (HDW80CH: 710×815×1995mm (15.1kW, 60 Racks/h) | HDW80L: 810×915×1605mm (15.75kW, Fits Sheet Pans & Trays)), this unit integrates directly into standardized commercial dishwashing lines with full factory spare-parts traceability.
Technical Specification Sheet & Sub-SKU Matrix
| Specification |
Value |
| IDENTITY |
| Model / Series Code | HDW80CH / HDW80L |
| Equipment Designation | Heat-Recovery Energy-Saving Commercial Hood-Type Pass-Through Dishwasher (HDW80CH / HDW80L) |
| PERFORMANCE & ELECTRICAL |
| Core Engineering Specs | HDW80CH: 710×815×1995mm (15.1kW, 60 Racks/h) | HDW80L: 810×915×1605mm (15.75kW, Fits Sheet Pans & Trays) |
| Power Supply / Energy Source | 380V–415V / 3Ph+N+PE / 50–60Hz |
| CONSTRUCTION & COMPLIANCE |
| Structural Material Grade | AISI 304 (1.2mm–1.5mm) deep-drawn wash tank, SUS316L booster heating elements & stainless steel anti-clog wash/rinse arms |
| Compliance & Design Standards | IEC 60335-2-58, NSF/ANSI 3 (Commercial Warewashing 82°C Thermal Sanitization), DIN 10510 / 10512, CE, SASO |
Sub-SKU Configuration Matrix (HS-DW100):
| Model | Feed Direction | Heating Method | Capacity (Racks/h) | Rinse Water (L/h) | Wash / Dry Power | Dimensions (mm) |
|---|
| HDW260-EL | Left-to-Right Feed | Electric Heating | 260 Racks/h | 320 - 400 L/h | 48.0 kW | 2050*810*1520 |
| HDW260-ER | Right-to-Left Feed | Electric Heating | 260 Racks/h | 320 - 400 L/h | 48.0 kW | 2050*810*1520 |
| HDW1500D-EL | Left-to-Right Feed | Electric Heating | 1500 Dishes/h | 250 - 320 L/h | 38.0 kW | 1750*820*1560 |
| HDW2000D-ER | Right-to-Left Feed | Electric Heating | 2000 Dishes/h | 280 - 350 L/h | 45.0 kW | 2150*820*1560 |
| HDW2000DL-ER | Right-to-Left (with Dryer) | Electric Heating + Ducted Hot-Air Drying | 2000 Dishes/h | 280 - 350 L/h | 45kW + Dryer 9kW | 2750*820*1560 |
Sub-SKU Configuration Matrix (HS-DW50):
| Model | Equipment Type | Power Supply | Rack Size | Wash Capacity | Rinse Water Consump. | Rated Power | Net Size (mm) | N.W. / G.W. |
|---|
| HDW80 | Pass-Through Hood Dishwasher | 380V/50Hz | 500*500 mm | 60 Racks/h | 3 L/Rack | 14.75 kW | 800*820*1470 | 106kg / 147kg |
| HDW80L | Hood Dishwasher (Low Energy) | 380V/50Hz | 500*500 mm | 60 Racks/h | 3 L/Rack | 14.75 kW | 800*820*1470 | 106kg / 147kg |
| HDW80CH | Hood Dishwasher (Heat Recov.) | 3N~380V/50Hz | 500*500 mm | 60 Racks/h | 3 L/Rack | 15.75 kW | 706*843*1475 | 106kg / 147kg |
Heat-Recovery Hood-Type Pass-Through Dishwasher
