Refrigerated Banquet Holding Cart (11/22-Tier)
Mobile Banquet Refrigerated Cold-Dish & Dessert Holding Cart (HSYL-YH-LCC (LC-CC-01 / 02)): B2B Engineering Overview
The Mobile Banquet Refrigerated Cold-Dish & Dessert Holding Cart (HSYL-YH-LCC 11/22-Tier) is an industrial-grade commercial refrigeration solution engineered for high-throughput hotels, central kitchens, and institutional catering across the Middle East (GCC) and Southeast Asia. Gentle, high-humidity chilled airflow preserves sashimi, cold appetizers, and desserts during banquet staging and transport. Fabricated with AISI 304 / sus201 brushed stainless steel interior & exterior with 60mm high-density cyclopentane (cfc-free) polyurethane insulation, it delivers verified operational output (LC-CC-01: 850×900×1800mm (280W, 11×GN2/1)LC-CC-02: 1550×900×1800mm (450W, 22×GN2/1)) under 220V–240V / 1Ph / 50Hz (or Dedicated 220V/60Hz Tropicalized Compressor for Saudi Arabia / Philippines) supply and complies with IEC 60335-2-89 (Commercial Refrigerating Appliances), ISO 23953-2 Climate Class 5 (43°C Ambient), NSF/ANSI 7, CE, SASO EER.
60mm Cyclopentane Insulation & 43°C Tropical Cooling
- Tropicalized Climate Class 5 Compressor (Embraco / Secop / Donper, Rated for 43°C Ambient): Oversized pure-copper finned condenser and high-displacement compressor maintain stable temperatures (LC-CC-01: 850×900×1800mm (280W, 11×GN2/1)LC-CC-02: 1550×900×1800mm (450W, 22×GN2/1)) even alongside hot Middle Eastern and Southeast Asian cooklines.
- 100% Pure Copper Tube Evaporator with Electrophoretic Anti-Corrosion Coating: Eliminates formicary acid corrosion and refrigerant pinhole leaks common in aluminum-coil chillers exposed to acidic salad dressings, seafood brine, and coastal humidity.
- 60mm High-Density Cyclopentane Foamed Body & Heavy-Duty Telescopic Drawers/Doors: Self-closing doors with removable triple-chamber magnetic gaskets (and 50kg-rated SUS304 drawer slides on E-CT chef bases) lock cold air inside during peak prep.
- Intelligent Dixell / Carel Digital Controller & Automatic Hot-Gas / Off-Cycle Defrost: Provides real-time LED temperature monitoring, high/low temp alarms, and energy-saving defrost management. Factory baseline configuration for HSYL-YH-LCC (LC-CC-01 / 02): Mobile Banquet Refrigerated Cold-Dish Holding Cart.
24/7 Cold-Chain Compressor Duty & 3.5 kWh/Day Refrigeration TCO
Because commercial refrigeration runs 24/7/365, compressor runtime efficiency and insulation thickness dominate 5-year TCO. With its 60mm cyclopentane foam barrier and eco-friendly R290/R404a tropicalized cooling circuit (averaging 52% compressor duty cycle over 24 hours), the HSYL-YH-LCC (LC-CC-01 / 02) consumes approximately 3.5 kWh/day—cutting annual electricity bills by 20%–28% compared to standard 40mm cabinets while operating below 56–60 dBA. Configured specifically as a Mobile Banquet Refrigerated Cold-Dish & Dessert Holding Cart (LC-CC-01: 850×900×1800mm (280W, 11×GN2/1)LC-CC-02: 1550×900×1800mm (450W, 22×GN2/1)), this unit integrates directly into standardized commercial commercial refrigeration lines with full factory spare-parts traceability.
Technical Specification Sheet & Sub-SKU Matrix
| Specification | Value |
|---|---|
| IDENTITY | |
| Model / Series Code | HSYL-YH-LCC (LC-CC-01 / 02) |
| Equipment Designation | Mobile Banquet Refrigerated Cold-Dish & Dessert Holding Cart (HSYL-YH-LCC 11/22-Tier) |
| PERFORMANCE & ELECTRICAL | |
| Core Engineering Specs | LC-CC-01: 850×900×1800mm (280W, 11×GN2/1)LC-CC-02: 1550×900×1800mm (450W, 22×GN2/1) |
| Power Supply / Energy Source | 220V–240V / 1Ph / 50Hz (or Dedicated 220V/60Hz Tropicalized Compressor for Saudi Arabia / Philippines) |
| CONSTRUCTION & COMPLIANCE | |
| Structural Material Grade | AISI 304 / SUS201 brushed stainless steel interior & exterior with 60mm high-density cyclopentane (CFC-free) polyurethane insulation |
| Compliance & Design Standards | IEC 60335-2-89 (Commercial Refrigerating Appliances), ISO 23953-2 Climate Class 5 (43°C Ambient), NSF/ANSI 7, CE, SASO EER |
| Model | Dimensions (mm) | Temp Range | Rated Voltage | Rated Power | Tray Capacity | Compressor Unit | Net Weight |
|---|---|---|---|---|---|---|---|
| LC-CC-01 | 850*900*1800 | 0 ~ +10 ℃ | 220V / 50Hz | 280 W | 11-Tier GN2/1 | Built-In Imported Secop Hermetic Compressor | 105 kg |
| LC-CC-02 | 1550*900*1800 | 0 ~ +10 ℃ | 220V / 50Hz | 450 W | 22-Tier GN2/1 | Built-In Imported Secop Hermetic Compressor | 175 kg |
