Stainless Steel Chef Garnish, Spice Rail & Expo Table
Commercial Stainless Steel Chef Garnish, Spice Rail & Expo Station Table (HSYL-BG-DH01 / DH02): B2B Engineering Overview
The Commercial Stainless Steel Chef Garnish, Spice Rail & Expo Station Table (HSYL-BG-DH01 / DH02) is an industrial-grade stainless steel solution engineered for high-throughput hotels, central kitchens, and institutional catering across the Middle East (GCC) and Southeast Asia. Central chef plating and garnish station with enclosed lower cabinet for plates and GN condiment pans. Fabricated with food-grade AISI 304 (1.2mm–1.5mm brushed stainless steel sheet, φ38×1.2mm tubular legs & omega reinforcement channels), it delivers verified operational output (1200 / 1500 / 1800 × 700/800 × 800+450(700)mm | Includes Upper 1/6 or 1/9 GN Spice Rail Overshelf & Lower Sliding-Door Cabinet) under Non-Electrical Structural Fabrication (Zero Power Consumption) supply and complies with NSF/ANSI 2 (Food Equipment Fabrication Standard), HACCP Hygienic Design Guidelines, ISO 9001 Quality Management.
Dual-Tier Inclined GN Spice Rail & Chef Expo Garnish Workstation
- Ergonomic Inclined Upper 1/6 & 1/9 GN Spice Pan Rail (1200 / 1500 / 1800 × 700/800 × 800+450(700)mm | Includes Upper 1/6 or 1/9 GN Spice Rail Overshelf & Lower Sliding-Door Cabinet): Positions 6 to 12 removable food-grade GN seasoning pans at a 25-degree ergonomic angle directly facing the wok/range chef for rapid one-handed seasoning.
- Sound-Deadened 1.2mm–1.5mm AISI 304 Prep Deck (200 kg Load Capacity): Reinforced with under-deck omega hat channels for heavy chopping board and hot-plate plating work.
- Enclosed Hygienic Sliding-Door / Flip-Up Base Cabinet: Keeps backup dry goods, sauces, and plating porcelain protected from kitchen grease and pests.
- Heavy-Duty Adjustable Stainless Bullet Feet (±35mm): Levels the garnish station flush against back-to-back cookline islands. Factory baseline configuration for HSYL-BG-DH01 / DH02: Sheet Thickness: True Gauge 0.8 / 1.0 / 1.2 mm; Base Structure: Sliding-Door or Open Stainless Steel Cabinet Base; Backsplash: 100mm Rear Splash Guard Upturn; Worktop Load: Reinforced Honeycomb Anti-Vibration Sub-Top, >300kg Load Capacity.
15-Year Corrosion Resistance & 65% Sea-Freight CBM Saving TCO
With zero electrical consumption (0 kWh/day) and zero moving mechanical wear parts, the total cost of ownership of the HSYL-BG-DH01 / DH02 is governed by sea-freight volume and corrosion longevity. Engineered in Knock-Down (K/D) flat-pack or nested export configurations, it reduces container CBM freight cost by up to 65% and packs into unused void spaces of your cooking/refrigeration container. Full 1.2mm–1.5mm AISI 304 construction eliminates rust replacement over a 15-year commercial kitchen lifecycle. Configured specifically as a Commercial Stainless Steel Chef Garnish, Spice Rail & Expo Station Table (1200 / 1500 / 1800 × 700/800 × 800+450(700)mm | Includes Upper 1/6 or 1/9 GN Spice Rail Overshelf & Lower Sliding-Door Cabinet), this unit integrates directly into standardized commercial stainless steel lines with full factory spare-parts traceability.
Technical Specification Sheet & Sub-SKU Matrix
| Specification | Value |
|---|---|
| IDENTITY | |
| Model / Series Code | HSYL-BG-DH01 / DH02 |
| Equipment Designation | Commercial Stainless Steel Chef Garnish, Spice Rail & Expo Station Table (HSYL-BG-DH01 / DH02) |
| PERFORMANCE & ELECTRICAL | |
| Core Engineering Specs | 1200 / 1500 / 1800 × 700/800 × 800+450(700)mm | Includes Upper 1/6 or 1/9 GN Spice Rail Overshelf & Lower Sliding-Door Cabinet |
| Power Supply / Energy Source | Non-Electrical Structural Fabrication (Zero Power Consumption) |
| CONSTRUCTION & COMPLIANCE | |
| Structural Material Grade | Food-grade AISI 304 (1.2mm–1.5mm brushed stainless steel sheet, Φ38×1.2mm tubular legs & omega reinforcement channels) |
| Compliance & Design Standards | NSF/ANSI 2 (Food Equipment Fabrication Standard), HACCP Hygienic Design Guidelines, ISO 9001 Quality Management |
| CATALOG BASELINE | |
| Catalog Sheet Thickness | True Gauge 0.8 / 1.0 / 1.2 mm |
| Catalog Base Structure | Sliding-Door or Open Stainless Steel Cabinet Base |
| Catalog Backsplash | 100mm Rear Splash Guard Upturn |
| Catalog Worktop Load | Reinforced Honeycomb Anti-Vibration Sub-Top, >300kg Load Capacity |
| COMPANION MODELS | |
| Companion Model (HSYL-BG-DH02) | Sheet Gauge: True Gauge 0.8 / 1.0 / 1.2 mm | Door Design: Flip-Up Overhead Slide Doors Prevent Aisle Obstruction | Door Sealing: Magnetic Seal blocks Dust & Insects | Build Standard: Full-Welded S/S with Seamless Hemmed Safety Edges |
