Undercounter Dishwasher with Water Softener & Drain Pump
Commercial Undercounter Dishwasher with Built-In Water Softener & Drain Pump (HDW50FCZ / HDW50FZ): B2B Engineering Overview
The Commercial Undercounter Dishwasher with Built-In Water Softener & Drain Pump (HDW50FCZ) is an industrial-grade dishwashing solution engineered for high-throughput hotels, central kitchens, and institutional catering across the Middle East (GCC) and Southeast Asia. Bar, cafe, and boutique bistro favorite. Compact under-counter installation, sparkling wine glasses without water spotting or manual wiping. Fabricated with AISI 304 (1.2mm–1.5mm) deep-drawn wash tank, sus316l booster heating elements & stainless steel anti-clog wash/rinse arms, it delivers verified operational output (600×600×820mm | 5.79kW (220V / 380V) | 500×500mm Dish Rack | Built-In Resin Water Softener) under 220V–240V / 1Ph or 380V–415V / 3Ph / 50–60Hz supply and complies with IEC 60335-2-58, NSF/ANSI 3 (Commercial Warewashing 82°C Thermal Sanitization), DIN 10510 / 10512, CE, SASO.
Built-In Automatic Resin Water Softener, Drain Pump & Undercounter Engineering
- Built-In Automatic Cation-Exchange Resin Water Softener (600×600×820mm | 5.79kW (220V / 380V) | 500×500mm Dish Rack | Built-In Resin Water Softener): Continuously strips calcium and magnesium ions from hard municipal water (up to 350+ ppm in GCC and SEA regions), preventing limescale buildup on the 82°C booster heater and leaving wine glasses spot-free.
- Integrated Forced-Drain Pump & Peristaltic Chemical Dispensers: Allows installation under 820mm bar and café counters even when the wall drain pipe is elevated up to 600mm above floor level.
- Double-Skinned Insulated AISI 304 Door & Whisper-Quiet (<59 dBA) Operation: Ideal for front-of-house specialty coffee bars, VIP lounges, and bistro kitchens.
- 90/120/180-Second Digital Wash Cycles (30–40 Racks/Hour): Consumes only 2.2 Liters of water per 500×500mm glass/dish rack. Factory baseline configuration for HDW50FCZ / HDW50FZ: Under-Counter Commercial Dishwasher.
Water, Chemical & 20.1 kWh/Day Stewarding TCO Analysis
In commercial stewarding operations, energy, water, and chemical dosing represent over 75% of lifecycle cost. Operating across a 6-hour peak washing schedule (58% effective heater duty factor), the HDW50FCZ / HDW50FZ consumes approximately 20.1 kWh/day while holding fresh rinse water consumption to just 2.0–2.4 Liters per rack. Tool-free removable stainless scrap screens and spray arms allow complete daily tank flushing in under 6 minutes. Configured specifically as a Commercial Undercounter Dishwasher with Built-In Water Softener & Drain Pump (600×600×820mm | 5.79kW (220V / 380V) | 500×500mm Dish Rack | Built-In Resin Water Softener), this unit integrates directly into standardized commercial dishwashing lines with full factory spare-parts traceability.
Technical Specification Sheet & Sub-SKU Matrix
| Specification | Value |
|---|---|
| IDENTITY | |
| Model / Series Code | HDW50FCZ / HDW50FZ |
| Equipment Designation | Commercial Undercounter Dishwasher with Built-In Water Softener & Drain Pump (HDW50FCZ) |
| PERFORMANCE & ELECTRICAL | |
| Core Engineering Specs | 600×600×820mm | 5.79kW (220V / 380V) | 500×500mm Dish Rack | Built-In Resin Water Softener |
| Power Supply / Energy Source | 220V–240V / 1Ph or 380V–415V / 3Ph / 50–60Hz |
| CONSTRUCTION & COMPLIANCE | |
| Structural Material Grade | AISI 304 (1.2mm–1.5mm) deep-drawn wash tank, SUS316L booster heating elements & stainless steel anti-clog wash/rinse arms |
| Compliance & Design Standards | IEC 60335-2-58, NSF/ANSI 3 (Commercial Warewashing 82°C Thermal Sanitization), DIN 10510 / 10512, CE, SASO |
| Model | Equipment Type | Power Supply | Rack Size | Wash Capacity | Rinse Water Consump. | Rated Power | Net Size (mm) | N.W. / G.W. |
|---|---|---|---|---|---|---|---|---|
| HDW40 | Undercounter Glasswasher | 230V/50Hz or 380V | 410*380 mm | 30 Racks/h | 3 L/Rack | 5.55 kW | 476*550*720 | 49kg / 63.2kg |
| HDW50 | Undercounter Dishwasher | 380V/50Hz or 230V | 500*500 mm | 30 Racks/h | 3 L/Rack | 7.05 kW | 600*610*820 | 65kg / 82kg |
| HDW50F | Front Dishwasher (Dispenser) | 220V/50Hz | 500*500 mm | 30 Racks/h | 3 L/Rack | 3.55 kW | 600*645*820 | 59kg / 67kg |
| HDW50FZ | Front Dishwasher (Booster) | 220V/50Hz | 500*500 mm | 30 Racks/h | 3 L/Rack | 3.59 kW | 600*645*820 | 67kg / 73kg |
| HDW50FC | Front Dishwasher (High-Power) | 380V/50Hz | 500*500 mm | 30 Racks/h | 3 L/Rack | 7.55 kW | 600*645*820 | 59kg / 67kg |
| HDW50FCZ | Front Dishwasher (Full-Spec) | 380V/50Hz | 500*500 mm | 30 Racks/h | 3 L/Rack | 7.59 kW | 600*645*820 | 67kg / 73kg |
