4-Tier Slatted & Perforated Stainless Steel Cold Room Rack
4-Tier Slatted & Perforated Stainless Steel Walk-In Cold Room Storage Rack (HSYL-BG-HJ02): B2B Engineering Overview
The 4-Tier Slatted & Perforated Stainless Steel Walk-In Cold Room Storage Rack (HSYL-BG-HJ02) is an industrial-grade stainless steel solution engineered for high-throughput hotels, central kitchens, and institutional catering across the Middle East (GCC) and Southeast Asia. Slatted shelves promote vertical cold-air circulation and water drainage, ideal for walk-in coolers and produce rooms. Fabricated with food-grade AISI 304 (1.2mm–1.5mm brushed stainless steel sheet, φ38×1.2mm tubular legs & omega reinforcement channels), it delivers verified operational output (1200 / 1500 / 1800 × 500 × 1550(1800)mm | 150kg Load Capacity per Shelf | Slatted Ventilation Tubes for Cold-Air Circulation & Dish Draining) under Non-Electrical Structural Fabrication (Zero Power Consumption) supply and complies with NSF/ANSI 2 (Food Equipment Fabrication Standard), HACCP Hygienic Design Guidelines, ISO 9001 Quality Management.
4-Tier Slatted Ventilation Tubes & 150 kg/Shelf Walk-In Cold Room Rack
- Open-Slatted / Perforated AISI 304 Ventilation Shelves (1200 / 1500 / 1800 × 500 × 1550(1800)mm | 150kg Load Capacity per Shelf | Slatted Ventilation Tubes for Cold-Air Circulation & Dish Draining): Maximizes vertical 360° cold-air circulation inside walk-in chillers/freezers (-25°C to +10°C) and accelerates water draining in dishwashing drying rooms.
- 150 kg Distributed Load Capacity Per Tier (600 kg Total Rack Load): Constructed from thickened stainless steel square tubing and cross-braced shelf frames that never bow under heavy meat crates or #10 cans.
- Knock-Down (K/D) Boltless/Bolted Export Flat-Pack Design: Reduces shipping volume by 70% inside 20GP/40HQ containers and assembles in 10 minutes inside narrow cold-room doors.
- Non-Corrosive AISI 304 Finish for High-Humidity Cold Rooms: Outlasts epoxy-coated wire shelving that peels and rusts after 18 months in damp walk-in coolers. Factory baseline configuration for HSYL-BG-HJ02: Sheet Gauge: True Gauge 0.8 / 1.0 / 1.2 mm; Slatted Design: High-Strength Slatted S/S Bars for Airflow & Drainage; Post Construction: Stainless Steel Legs with Non-Slip Floor-Protecting Feet; Operating Environment: Walk-In Coolers, Dish Drying Rooms & Produce Storage.
15-Year Corrosion Resistance & 65% Sea-Freight CBM Saving TCO
With zero electrical consumption (0 kWh/day) and zero moving mechanical wear parts, the total cost of ownership of the HSYL-BG-HJ02 is governed by sea-freight volume and corrosion longevity. Engineered in Knock-Down (K/D) flat-pack or nested export configurations, it reduces container CBM freight cost by up to 65% and packs into unused void spaces of your cooking/refrigeration container. Full 1.2mm–1.5mm AISI 304 construction eliminates rust replacement over a 15-year commercial kitchen lifecycle. Configured specifically as a 4-Tier Slatted & Perforated Stainless Steel Walk-In Cold Room Storage Rack (1200 / 1500 / 1800 × 500 × 1550(1800)mm | 150kg Load Capacity per Shelf | Slatted Ventilation Tubes for Cold-Air Circulation & Dish Draining), this unit integrates directly into standardized commercial stainless steel lines with full factory spare-parts traceability.
Technical Specification Sheet & Sub-SKU Matrix
| Specification | Value |
|---|---|
| IDENTITY | |
| Model / Series Code | HSYL-BG-HJ02 |
| Equipment Designation | 4-Tier Slatted & Perforated Stainless Steel Walk-In Cold Room Storage Rack (HSYL-BG-HJ02) |
| PERFORMANCE & ELECTRICAL | |
| Core Engineering Specs | 1200 / 1500 / 1800 × 500 × 1550(1800)mm | 150kg Load Capacity per Shelf | Slatted Ventilation Tubes for Cold-Air Circulation & Dish Draining |
| Power Supply / Energy Source | Non-Electrical Structural Fabrication (Zero Power Consumption) |
| CONSTRUCTION & COMPLIANCE | |
| Structural Material Grade | Food-grade AISI 304 (1.2mm–1.5mm brushed stainless steel sheet, Φ38×1.2mm tubular legs & omega reinforcement channels) |
| Compliance & Design Standards | NSF/ANSI 2 (Food Equipment Fabrication Standard), HACCP Hygienic Design Guidelines, ISO 9001 Quality Management |
| CATALOG BASELINE | |
| Catalog Sheet Gauge | True Gauge 0.8 / 1.0 / 1.2 mm |
| Catalog Slatted Design | High-Strength Slatted S/S Bars for Airflow & Drainage |
| Catalog Post Construction | Stainless Steel Legs with Non-Slip Floor-Protecting Feet |
| Catalog Operating Environment | Walk-In Coolers, Dish Drying Rooms & Produce Storage |
| COMPANION MODELS | |
| Companion Model (HSYL-BG-HJ01) | Sheet Thickness: True Gauge 0.8 / 1.0 / 1.2 mm | Leg / Post Spec: Φ38mm Heavy S/S Round Posts or 38×38mm Square Tubing | Load Capacity: >120kg Uniform Load per Tier, Multi-Position Adjustable Height | Build Standard: Triple-Hemmed Safety Edges, Heavy-Load Deformation Resistant |
