Walk-In Hot-Air Sterilization Room (2/3/4-Trolley)

Modular Walk-In Commercial High-Temp Hot-Air Sterilization Room (HSYL-XDF / HSYL-TC-72): B2B Engineering Overview

The Modular Walk-In Commercial High-Temp Hot-Air Sterilization Room (HSYL-XDF 2/3/4-Trolley) is an industrial-grade sterilization solution engineered for high-throughput hotels, central kitchens, and institutional catering across the Middle East (GCC) and Southeast Asia. Custom-sized walk-in thermal disinfection chamber for hotel banquets, central meal distribution centers, and hospitals. Fabricated with AISI 304 / anti-fingerprint brushed stainless steel chamber, 45mm–50mm high-density polyurethane/rock-wool insulation & 6mm solid SUS304 racks, it delivers verified operational output (XDF-02: 2000×1400×2200 (18kW) | XDF-03: 3000×1400×2200 (24kW) | XDF-04: 4000×1400×2200 (36kW, 380V, 120–150°C)) under 380V–415V / 3Ph+N+PE / 50–60Hz supply and complies with IEC 60335-2-58 / GB 17988 (2-Star Escherichia coli & Poliovirus Inactivation), HACCP Sanitation Standard, CE.

125°C–150°C 3D Hot-Air Circulation Sterilization

• 125°C–150°C Far-Infrared / 3D Forced Hot-Air Circulation (XDF-02: 2000×1400×2200 (18kW) | XDF-03: 3000×1400×2200 (24kW) | XDF-04: 4000×1400×2200 (36kW, 380V, 120–150°C)): Achieves 2-Star hospital-grade thermal inactivation of E. coli, Staphylococcus aureus, and Hepatitis/Poliovirus across dense stacks of porcelain, glass, and stainless steel tableware.
• 45mm–50mm High-Density Thermal Insulation & Silicone Magnetic Gasket: Locks thermal energy inside the cavity so outer cabinet walls remain below 45°C even during peak 125°C–150°C sterilization cycles.
• Modular Knock-Down Chamber / Flush Floor Roll-In Banquet Trolley Track: Eliminates manual loading and unloading of thousands of canteen trays—stewards wheel dish trolleys directly from the conveyor dishwasher into the sterilization chamber.
• Microcomputer LED Cycle Timer & Door-Open Safety Interlock: Automatically cuts UV-C, ozone, and heating elements the instant a door is opened during operation. Factory baseline configuration for HSYL-XDF / HSYL-TC-72: Modular Walk-In High-Temp Hot-Air Sterilization Chamber.

HACCP Pathogenic Inactivation & 108.00 kWh/Day Sterilization TCO

In humid Southeast Asian and GCC institutional kitchens, damp tableware stored on open shelves rapidly breeds mold and coliform bacteria. Running two 60-to-90-minute sanitization and drying cycles per day on the HSYL-XDF / HSYL-TC-72 consumes approximately 108.00 kWh/day, keeping sanitized tableware, knives, or cleanroom garments in a sealed, positive-pressure sterile environment for 24 hours. Long-life heating tubes (>8,000h) and plug-in digital PCBs ensure minimal maintenance cost. Configured specifically as a Modular Walk-In Commercial High-Temp Hot-Air Sterilization Room (XDF-02: 2000×1400×2200 (18kW) | XDF-03: 3000×1400×2200 (24kW) | XDF-04: 4000×1400×2200 (36kW, 380V, 120–150°C)), this unit integrates directly into standardized commercial sterilization lines with full factory spare-parts traceability.

Technical Specification Sheet & Sub-SKU Matrix
